Electrical parametri
| Pro*prium | Symbolum | Min | Typ | Max | Unitas |
| Vs=5.0V (MCP-H20-A series) | V S | 4.75 | 5.0 | 5.25 | VDC |
| Vs=3.3V (MCP-H20-B series) | V S | 3 | 3.3 | 3.6 | VDC |
| opus current | I o | - | 3 | ma DC | |
| Accuracy（0℃ ad 85℃） | - | - | - | 1.5 | %V FSS |
| ADC resolutio | RES ADC | - | 24 | - | bit |
| DAC resolutio | RES DAC | - | 12 | - | bit |
| Responsum tempus | t R | - | 2.5 | - | ms |
| Fermentum tempus | - | - | 100 | - | ms |
| ESD Praesidium | - | - | 2 | - | kV |
Output parametri
MCP-H20-A series (Power Supple Voltage: 5.0V)
| Proprium | Symbolumum | Min | Typ | Max | Unitasas |
| Min pressura offset (0℃ ad 85℃) | V off | 0.44 | 0.5 | 0.56 | VDC |
| Plena eu output (0℃ ad 85℃) | V FSO | 4.44 | 4.5 | 4.56 | VDC |
| Plena spatio (0℃ ad 85℃) | V FSS | 3.88 | 4 | 4.12 | VDC |
series MCP-H20-B (Power Supple Voltage: 3.3V)
| Proprium | Symbolumum | Min | Typ | Max | Unitasas |
| Min pressura offset (0℃ ad 85℃) | V off | 0.055 | 0.1 | 0.145 | VDC |
| Plena eu output (0℃ ad 85℃) | V FSO | 3.055 | 3.1 | 3.145 | VDC |
| Plena spatio (0℃ ad 85℃) | V FSS | 2.91 | 3 | 3.09 | VDC |
Pressura et Temperature Characteres
Table1: Impetus Output Characteres @ VDD = 5.0V, T = 25 nisi aliter notetur
| Parameter | Symbolumum | Conditiones | Min | Typ. | Max | Unitasas |
| Pressura mensurae dolor 1 | PFS | -100 | 200 | Kpa | ||
| Pressura resolutio | Pressura | 0.05 | %FS | |||
| Pressura Accuracy 2 | Ad 25℃ | -0.1 | 0.1 | %FS | ||
| Summa Error Band 3 | TEB | Ab 25℃ ad 60℃ | -0.3 | 0.3 | %FS | |
| Ab -40℃ ad 85℃ | -1 | 1 | %FS | |||
| Long Term Drift | Post periodum I annos | ±0.15 | %FS | |||
| Reflow solidatorium impulsum | IPC/JEDEC J-STD-020C | ±0.2 | %FS |
1. Alta pressio latus est in latere notato.
2. Maxima declinatio ab aptissima recta (BFSL) ad output aptata supra pressionis range 25C mensuratur. Omnes errores propter pressionem non linearitatem, hysteresim et non iterabilitatem includit.
3. Tota pressio errorum cohortis includit omnes errores accurationis, errores scelerisque in recompensatione extensionis et spatiorum et cinguli calibrationis tolerantias. Pro idealium sensorem output respectu input pressionis et caliditatis, valores TEB tantum valent ad copiam intentionis calibratae.
Table2: Temperature Output Characteres @ VDD = 5.0V, T = 25°C nisi aliter note
| Parameter | Symbolumum | Conditiones | Min | Typ. | Max | Unitasas |
| Operatio Temperature | T OP* | -20 | 85 | ℃ | ||
| Temperature Absoluta Accuracy | -10℃ ad 50℃ | ±1.0 | ℃ | |||
| Max Error in Power | Potentia copia ab 1.8V ad 5.5V | ±0.1 | ℃ | |||
| Temperature Resolutione de Output Data | 0.01 | ℃ |
Characteres electrici
Table3: DC Characteres @VDD=5.0 V, T=25, nisi aliter note
| Parameter | Symbolum | Conditiones | Min | Typ. | Max | Unitas |
| Operatio mediocris Current | I DDAVP | Una Conversio per Second | 4.5 | 6.4 | μA | |
| Apicem Current | I POCUM | Pressura conversionem | 1.5 | ma | ||
| Temperatus conversionem | 0.95 | ma | ||||
| Standby Supple Current | I DDSTB | Ad 25℃ | 0.2 | μA | ||
| Vide Data Pro Frequency | f* SCLK | I 2 C protocol, viverra-sursum resistor 4.7k | 100 | 400 | kHz | |
| Digital Input High intentione | VIH | 0.8 | V | |||
| Digital Input Low Voltage | VII | 0.2 | V | |||
| Digital Output High intentione | V OH | IO = 0.5 mA | 0.9 | V | ||
| Digital Output Low intentione | V OL' | IO = 0.5 mA | 0.1 | V | ||
| Input Capacitance | C IN' | 10 | pF* | |||
| I2C excute-Up Resistors | R PU | 3.3 | 4.7 | 10 | KΩ |
Maximum Rating
Tabula 4: Absoluta Maximum Rating
| Parameter | Symbolum | Conditiones | Min | Max | Unitas |
| Overpressure | P MAX | 3X | |||
| Supple intentione | V DD | -0.3 | 6.5 | V | |
| Interface Voltage | V SI* | -0.3 | VDD 0.3 | V | |
| Repono Temperature Range | T STG | -40 | 150 | ℃ | |
| Maximum Solding Temperature | T MS | X secundo maximum | 250 | ℃ | |
| ESD Rating | Humanum corpus exemplar | -2 | 2 | kV |
Patefacio maximus rating condiciones protractis afficiat fabrica constantiam.
