Maximum Ratings (MCP-J10)
| Morbi laoreet | Symbolum | Range | Unitas |
| Analoga copia voltage | VDD | -0.3 ad 6.0 | V |
| operating temperatus | -40 ad 125 | ℃ | |
| Repono temperatus | -50 ad 150 | ℃ | |
| Coniunctio temperatus | 150 | ℃ | |
| ESD susceptibilitatem | HBM | 4 | kV |
Nota: Rating absolutus maximus potest facere detrimentum permanentem, et operationem diuturnam ad maximum supra absolutum aestimationem pertinere potest fidei fabricae..
Electrical Characteristic (MCP-J10)
Tabula 1. Characteres Operantes (VS = 5.0 Vdc, TA = 25°C, nisi aliter notetur)
| Morbi laoreet | Symbolumum | Min | Typ | Max | Unitasas |
| Supple intentione | VS | 4.75 | 5 | 5.25 | Vdc |
| Supple Current | Io | - | 3 | mAdc | |
| Offset (0°C ad 85°C) @ VS = 5.0Volts | Voff | 0.44 | 0.5 | 0.56 | Vdc |
| Plena Scala Output (0°C ad 85°C) @ VS = 5.0V | VFSO | 4.44 | 4.5 | 4.56 | Vdc |
| Scala plena (0 ad 85 ) @ VS=5.0V | VFSS | 3.88 | 4 | 4.12 | Vdc |
Perge Tabula 1. Characteres Operantes (VS = 5.0 Vdc, TA = 25°C, nisi aliter notetur)
| Morbi laoreet | Symbolumum | Min | Typ | Max | Unitasas |
| Sagaciter (0°C ad 85°C) | - | - | - | 2.5 | %VFSS |
| Responsio Tempus | tR* | - | 2.5 | - | ms |
| Fermentum Tempus | - | - | 100 | - | ms |
| Offset stabilitas | - | - | 0.25 | - | %VFSS |
Ultima aestimatio (MCP-J20)
| modulus | symbolum | range | unitas |
| Simulate potentia copia voltage | VDO | -0.3 ~ 6.0 | V |
| Digital Supple voltage | VDOF | -0.3 ~ 2.2 | V |
| Opus temperatus range | -40 ~125 | ℃ | |
| Repono Temperature Range | -50 ~150 | ℃ | |
| Coniunctio temperatus | 150 | ℃ | |
| ESD range | HBM | 4KV | V |
Nota: Excedens valorem absolutum maximum aestimatum potest damnum permanentem facere, et operatio prolongata apud absolutum maximum valorem aestimatum potest afficere artificii fidem..
Parametri electrica (MCP-J20)
Tabula 1 Operationis characteres (VS=5.0 Vdc, TA=25°C nisi aliud certum)
| proprium | signumum | minimum | Typical values | maximum | unitasas |
| voltage | VS | 4.75 | 5 | 5.25 | Vdc |
| Potentia copia current | Io | - | 3 | mAdc | |
| Minimum pressionis output (0 ad 85 ℃) VS=5.0 V | Voff | 0.4 | 0.5 | 0.6 | Vdc |
| Full range output (0 to 85 ) VS=5.0 volts | VFSO | 4.4 | 4.5 | 4.6 | Vdc |
| Plena range (0 ad 85 ) VS=5.0 volts | VFSS | 3.8 | 4 | 4.2 | Vdc |
| Sagaciter (0 ad 85 ) | - | - | - | 2.5 | %VFSS |
| Proprium | signumum | minimum | Typical values | maximum | unitasas |
| Responsum tempus | tR* | - | 1 | - | ms |
| Inebriat tempus | - | - | 100 | - | ms |
| ESD tutela | - | - | 4 | - | kV |
